高温热处理对杨木PF浸渍材尺寸稳定性的影响

徐康; 吕建雄; 李贤军; 吴义强

doi:10.13332/j.1000-1522.20150019

高温热处理对杨木PF浸渍材尺寸稳定性的影响

徐康^1,2,
吕建雄^1, ,,
李贤军²,
吴义强²

1.
1 中国林业科学研究院木材工业研究所;
2.
2 中南林业科技大学材料科学与工程学院

基金项目:

“十二五”国家科技支撑计划项目(2012BAD24B02)、国家自然科学基金项目(31370564)。

详细信息

作者简介:
徐康,博士生。主要研究方向:木材功能性改良。Email:xkang86@126.com 地址:100091 北京市颐和园后中国林业科学研究院木材工业研究所。

责任作者:
吕建雄,博士,研究员。主要研究方向:木材物理与干燥。 Email:jianxiong@caf.ac.cn 地址:同上。

计量
- 文章访问数: 1938
- HTML全文浏览量: 245
- PDF下载量: 25
出版历程
- 收稿日期: 2014-01-05
- 发布日期: 2015-09-29

Effect of heat treatment on dimensional stability of phenolic resin impregnated poplar wood.

1.
1.Research Institute of Wood Industry, Chinese Academy of Forestry, Beijing, 100091, P.R. China;
2.
2.Material Science and Engineering School of Central South University of Forestry and Technology, Changsha, 410004, P.R. China.

摘要

摘要: 为研究高温热处理对杨木PF浸渍材尺寸稳定性的影响,对速生杨木素材和PF浸渍材进行高温热处理,系统研究杨木素材、PF浸渍材、热处理材和PF浸渍-热处理材的吸水性、线性(径向和弦向)和体积吸水膨胀率、吸湿含水率、表面润湿性。结果表明:高温热处理可显著降低材料的吸水性、吸水膨胀率、吸湿含水率、表面润湿性,提高尺寸稳定性。相比于素材,浸水8 d后,PF浸渍材吸水量降低了17.37%,热处理材最高降低了63.8%,PF浸渍-热处理材最高降低了74.7%;PF浸渍材径向、弦向及体积吸水膨胀率分别降低14.71%、36.93%、30.19%,热处理材最高分别降低了64.99%、74.94%、72.33%,PF浸渍-热处理材最高分别降低94.4%、90.61%、91.37%;PF浸渍材吸湿含水率降低了11.14%,热处理材最高降低了55.57%,PF浸渍-热处理材最高降低了60.62%。与素材相比,PF浸渍材的表面接触角相差不大,热处理材最高提高了143.7%,PF浸渍-热处理材最高提高了139.4%,后2种木材的表面润湿性明显降低。相同热处理条件下,PF浸渍-热处理材尺寸稳定性更优异。红外光谱图中,PF浸渍材羟基、羰基和羧基吸收峰减弱、苯环碳骨架振动加强,热处理后羟基和乙酰基吸收峰减弱,表明PF浸渍处理和热处理对木材亲水性基团的减少和尺寸稳定性提高均有贡献,作为一种联合改性技术对于速生材尺寸稳定性的提高和开发利用具有实际意义。
- 杨木 /
- 高温热处理 /
- PF浸渍材 /
- 尺寸稳定性
Abstract: The poplar wood and phenol formaldehyde (PF) impregnated wood were subjected to heat treatment at 160, 180, 200 and 220 ℃ for 1 to 4 hrs. Hydroscopicity, hygroscopicity, linear (radial and tangential) and volume swelling, and surface wettability of the control and PF impregnated wood after heat treatment were measured. The results showed that the dimensional stability can be improved considerably after heat treatment. The water absorption of PF impregnated wood was reduced by 17.37% compared with that of control group after soaking in water for eight days, and the maximum decline could reach up to 63.8% and 74.7% for heat-treated wood and PF impregnated heat-treated wood, respectively. The swelling ratio of PF impregnated wood was reduced by 14.71%, 36.93%, and 30.19% for radial, tangential, and volume, respectively, as compared to that of untreated wood, whereas the maximum reduction could reach up to 64.99%, 74.94%, and 72.33% for heat-treated wood and 94.4%, 90.61%, and 91.37% for PF impregnated heat-treated wood. The adsorption moisture content decreased by 11.14% for PF impregnated wood compared with that of control group, while 55.57% and 60.62% reduction was observed for heat-treated wood and PF impregnated heat-treated wood, respectively. The contact angle of PF impregnated was close to that of control group, while the maximum increase could reach up to 143.7% and 139.4% for heat-treated wood and PF impregnated heat-treated wood, respectively, indicating that the surface wettability of heat-treated wood and PF impregnated heat-treated wood were decreased significantly. After heat treatment, significant changes can be found in infrared spectrogram. The improved dimensional stability of PF impregnated heat-treated wood was attributed to the reduction of hydroxyl, carboxyl and carbonyl which was mainly caused by the degradation of hemicellulose and the formation of chemical bonds between PF resin components and the cell wall polymers. PF resin impregnation combined with heat treatment was one of effective methods to improve the dimensional stability of poplar wood.
- poplar /
- heat treatment /
- phenolic resin impregnated wood /
- dimensional stability

HTML全文

参考文献(27)

[2]	WANG Q W. Process in fire retardant for wood[J]. Journal of Northeast Forestry University,1999,27(6):85-90.
[2]	王清文.木材阻燃剂技术进展[J].东北林业大学学报,1999,27(6):85-90.
[3]	JIANG M L. Current states of research and development of new wood preservation technology[J]. China Wood Industry,2006,20(2):23-25.
[3]	蒋明亮.国内外木材防腐新技术的开发与应用[J].木材工业,2006,20(2):23-25.
[4]	HILL C A S. Wood modification: chemical, thermal and other processes[M]. New York: John Wiley Sons,2007.
[4]	CAO Y J, L J X, SHUN Z Y, et al. Development and application of overseas heat-treated wood[J]. Scientia Silvae Sinicae,2007,43(2):104-110.
[5]	LU W D, ZHAO G J, ZHOU Y G, et al. The relationship between acetylated degree and the dimensional stability of treated wood[J]. Journal of Northeast Forestry University,1995,23(5):72-75.
[5]	曹永建,吕建雄,孙振鸢,等.国外木材热处理工艺进展及制品应用[J].林业科学,2007,43(2):104-110.
[6]	陆文达,赵广杰,周亚光,等.乙酰化度与处理材的尺寸稳定性[J].东北林业大学学报,1995,23(5):72-75.
[6]	LIU Z S, ZHANG Q L, ZHANG Q S. Manufacturing technology of compressed wood[J]. China Wood Industry,2000,14(5):19-21.
[7]	LIU J L, JIANG Z H, SUN J J. Measurement the physical-mechanical properties of poplar lumber by PF resin treatment[J]. Scientia Silvae Sinicae,2002,38(4):176-180.
[7]	WANG X Q, LIU S C, CHANG H J, et al. Sol-Gel deposition of TiO2 nanocoatings on wood surfaces with enhanced hydrophobicity and photostability[J]. Wood and Fiber Science,2014,46(1):109-117.
[8]	LI L Z, YANG C X, SONG Z M, et al. Performance of eucalyptus lumber after resin impregnation and heat treatment[J]. China Wood Industry,2009,23(3):40-42.
[8]	刘占胜,张勤丽,张齐生.压缩木制造技术[J].木材工业,2000,14(5):19-21.
[9]	XU K, L J X, LI X J,et al. Process of wood high intensity microwave pretreatment based on response surface methodology[J]. Scientia Silvae Sinicae,2014,50(11):109-114.
[9]	刘君良,江泽慧,孙家杰.酚醛树脂处理杨树木材物理力学性能测试[J].林业科学,2002,38(4):176-180.
[10]	DEKA M, SAIKIA C N. Chemical modification of wood with thermosetting resin:effect on dimensional stability and strength property[J]. Bioresource Technology,2000,73(2):179-181.
[10]	GBT1934-1—2009 Method for determination of the water absorption of wood[S]. Beijing: Standards Press of China,2009.
[11]	李龙哲,阳财喜,宋作梅,等.桉树木材的浸渍增强热处理技术[J].木材工业,2009,23(3):40-42.
[11]	YIN S C. Wood science[M]. Beijing: China Forestry Publishing House,1996:123-125.
[12]	SUN B L, WANG X H, LIU J L. Changes in dimensional stability and mechanical properties of Eucalyptus pellita by melamine-urea-formaldehyde resin impregnation and heat treatment[J]. European Journal of Wood and Wood Products,2013,71(5):557-562.
[12]	YANG C X, YAN H P, LIU J L. Surface performance of eucalyptus lumber after vacuum-heat treatment[J]. Scientia Silvae Sinicae,2010,46(10):130-134.
[13]	徐康,吕建雄,李贤军,等.基于响应曲面优化法的木材高强微波预处理工艺[J].林业科学,2014,50(11):109-114.
[14]	XU K, WANG Y, L J X, et al. The effect of microwave pretreatment on the impregnation of poplar wood[J]. Bioresources, 2014,10(1):282-289.
[15]	GBT1934-1—2009木材吸水性测试方法[S].北京:中国标准出版社,2009.
[16]	尹思慈.木材学[M].北京:中国林业出版社,1996:123-125.
[17]	阳财喜,阎昊鹏,刘君良.桉树真空热处理材表面性能分析[J].林业科学,2010,46(10):130-134.
