基于MODIS数据的内蒙古地形因子对火灾分布的影响分析

贾旭 高永 魏宝成 杨光 党晓宏 任昱 梁超

贾旭, 高永, 魏宝成, 杨光, 党晓宏, 任昱, 梁超. 基于MODIS数据的内蒙古地形因子对火灾分布的影响分析[J]. 北京林业大学学报, 2017, 39(5): 34-40. doi: 10.13332/j.1000-1522.20170006
引用本文: 贾旭, 高永, 魏宝成, 杨光, 党晓宏, 任昱, 梁超. 基于MODIS数据的内蒙古地形因子对火灾分布的影响分析[J]. 北京林业大学学报, 2017, 39(5): 34-40. doi: 10.13332/j.1000-1522.20170006
JIA Xu, GAO Yong, WEI Bao-cheng, YANG Guang, DANG Xiao-hong, REN Yu, LIANG Chao. Impact of topographic features on the distribution of fire based on MODIS data in Inner Mongolia, northern China[J]. Journal of Beijing Forestry University, 2017, 39(5): 34-40. doi: 10.13332/j.1000-1522.20170006
Citation: JIA Xu, GAO Yong, WEI Bao-cheng, YANG Guang, DANG Xiao-hong, REN Yu, LIANG Chao. Impact of topographic features on the distribution of fire based on MODIS data in Inner Mongolia, northern China[J]. Journal of Beijing Forestry University, 2017, 39(5): 34-40. doi: 10.13332/j.1000-1522.20170006

基于MODIS数据的内蒙古地形因子对火灾分布的影响分析

doi: 10.13332/j.1000-1522.20170006
基金项目: 内蒙古自治区林业厅项目“森林灾害风险区划及评估”
详细信息
    作者简介:

    贾旭。主要研究方向:自然灾害监测与防治。Email:jx84711230@126.com   地址:010018  内蒙古自治区呼和浩特市赛罕区鄂尔多斯东街29号沙漠治理学院

    责任作者:

    高永,博士,教授。主要研究方向:荒漠化防治。Email:13948815709@163.com   地址:同上

  • 中图分类号: S762.3+2

Impact of topographic features on the distribution of fire based on MODIS data in Inner Mongolia, northern China

  • 摘要: 了解火灾与地形因子的关系是深入研究火灾空间分布格局、火灾风险科学管理的重要前提。本研究基于MOD14A1/MYD14A1热异常产品数据集提取内蒙古2000—2015年的火点信息,结合研究区DEM数据,提取相关地形因子,并在此基础上分析区域尺度背景下的地形因子与火灾分布关系。结果表明:1)采用均值变点分析法,确定内蒙古地形起伏度的最佳统计单元为0.52 km2;2)火灾分布在地形因子的作用下表现出一定的地形梯度性。火点个数随高程的升高呈现先增大后减小的变化趋势,而火点个数随坡度和地形起伏度的增大呈现逐渐下降的趋势;3)火点分布最多的高程、坡度、地形起伏度区间分别为80~700 m、0°~7°、1~70 m,火灾多发生在高程低、地形平坦、起伏小的地区,这类区域一般人类活动频繁,为火灾的发生提供了机会;4)在火点分布最多的地形区间内,不同土地利用类型上的火点个数分布排序为草地>耕地>林地>其他类型。



  • 图  1  SSi差值变化曲线

    S代表总的样本离差平方和,Si代表分段样本离差平方和。

    Figure  1.  Change curve of difference between S and Si

    S and Si represent sum of squares of total sample deviation and sum of squares of partial sample deviation, respectively.

    图  2  研究区高程、坡度、地形起伏度分级图

    Figure  2.  Hierarchical map of elevation, slope degree and amplitude of landform in the study area

    图  3  单位高程上的火点个数

    Figure  3.  Number of firepots per elevation unit

    图  4  单位坡度上的火点个数

    Figure  4.  Number of firepots per slope degree unit

    图  5  单位地形起伏度上的火点个数

    Figure  5.  Number of firepots per unit amplitude of landform

    表  1  Fire Mask数据集属性值含义

    Table  1.   Specific content of 10 levels of fire mask

    属性值
    Attribute value
    对应具体含义
    Corresponding meaning
    0 未处理像元Unprocessed pixel
    1 未处理像元Unprocessed pixel
    2 未处理像元Unprocessed pixel
    3 水域Water pixel
    4 云Cloud
    5 没有火的裸地Non-fire bare land pixel
    6 未知像元Unknown pixel
    7 低置信检测火点Fire (low confidence, land or water)
    8 中置信检测火点Fire (middle confidence, land or water)
    9 高置信检测火点Fire (high confidence, land or water)
    下载: 导出CSV

    表  2  各地形因子级别区所占面积和比例

    Table  2.   Area and proportion of different topographic factor levels

    地形因子Topographic factor 1 2 3 4 5 6 7 8
    高程
    Elevation
    范围Range/m 80~300 300~500 500~700 700~900 900~1 100 1 100~1 300 1 300~1 500 >1 500
    面积Area/km2 65 448 77 403 118 107 124 043 240 489 196 732 219 958 101 045
    百分比Percentage/% 6 7 10 11 21 17 19 9
    坡度
    Slope degree
    范围Range/(°) 0~2 2~7 7~15 15~25 25~35 >35
    面积Area/km2 656 341 308 657 141 939 32 935 3 069 283
    百分比Percentage/% 57 27 12 3 0 0
    地形起伏度
    Amplitude of
    landform
    范围Range/m 1~30 30~70 70~200 200~500
    面积Area/km2 690 749 220 245 222 057 14 592
    百分比Percentage/% 60 19 19 1
    下载: 导出CSV

    表  3  火点个数在不同高程级别区的分布

    Table  3.   Distribution of firepots at different elevation levels

    项目Item 1 2 3 4 5 6 7 8
    高程值Elevation value/m 80~300 300~500 500~700 700~900 900~1 100 1 100~1 300 1 300~1 500 >1 500
    火点个数Number of firepot 1 993 2 972 2 316 1 797 1 197 935 593 199
    百分比Percentage/% 17 25 19 15 10 8 5 2
    下载: 导出CSV

    表  4  火点个数在不同坡度级别区的分布

    Table  4.   Distribution of firepots at different slope levels

    项目Item 1 2 3 4 5 6
    坡度值Slope degree value/(°) 0~2 2~7 7~15 15~25 25~35 >35
    火点个数Number of firepot 5 071 4 361 2 267 290 11 2
    百分比Percentage/% 42 36 19 2 0 0
    下载: 导出CSV

    表  5  火点个数在不同地形起伏度级别区的分布

    Table  5.   Distribution of firepots at different levels of amplitude of landform

    项目Item 1 2 3 4
    地形起伏度值Amplitude value of landform/m 1~30 30~70 70~200 >200
    火点个数Number of firepot 4 780 3 602 3 528 92
    百分比Percentage/% 40 30 29 1
    下载: 导出CSV
  • [1] VAZQUEZ A, MORENO J M. Spatial distribution of forest fires in Sierra de Gredos(Central Spain)[J]. Forest Ecology and Management, 2001, 147(1): 55-65. doi: 10.1016/S0378-1127(00)00436-9
    [2] VIVCHAR A. Wildfires in Russia in 2000-2008:estimates of burnt areas using the satellite MODIS MCD45 data[J]. Remote Sensing Letters, 2011, 2(1): 81-90.
    [3] WOOLFORD D, DEAN C, MARTELL D, et al. Lightning-caused forest fire risk in northwestern Ontario, Canada, is increasing and associated with anomalies in fire weather[J]. Environmetrics, 2014, 25(6): 406-416. doi: 10.1002/env.2278
    [4] MARTINEZ J, VEGA-GARCIA C, CHUVIECO E. Human-caused wildfire risk rating for prevention planning in Spain[J]. Journal of Environmental Management, 2009, 90(2): 1241-1252. doi: 10.1016/j.jenvman.2008.07.005
    [5] ARAGAO L E O C, MALHI Y, ROMAN-CUESTA R M, et al. Spatial patterns and fire response of recent Amazonian droughts[J]. Geophysical Research Letters, 2007, 34: 488-501. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=10.1029/2006GL028946
    [6] ARAGAO L E O C, MALHI Y, BARBIER N, et al. Interactions between rainfall, deforestation and fires during recent years in the Brazilian Amazonia[J]. Philophical Transactions of the Royal Society B, 2008, 363: 1779-1785. doi: 10.1098/rstb.2007.0026
    [7] ARAUJO F M D, FERREIRA L G, ARANTES A E. Distribution patterns of burned areas in the Brazilian biomes: an analysis based on satellite data for the 2002-2010 period[J]. Remote Sensing, 2012, 4(1): 1929-1946. http://d.old.wanfangdata.com.cn/OAPaper/oai_doaj-articles_421465c1fe111e817335c4bbfdadc3d9
    [8] TIAN X R, ZHAO F J, SHU L F, et al. Distribution characteristics and the influence factors of forest fires in China[J]. Forest Ecology and Management, 2013, 310(1): 460-467. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=012518e6e48e28fcfb83ddf1b0553dde
    [9] 贺宝华, 陈良富, 陶金花, 等.基于观测几何的环境卫星红外相机遥感火点监测算法[J].红外与毫米波学报, 2011, 30(2): 104-114. http://d.old.wanfangdata.com.cn/Periodical/hwyhmb201102002

    HE B H, CHEN L F, TAO J H, et al. A contextual fire detection algorithm based on observation geometry for HJ-1B-IRS[J]. Journal of Infrared and Millimeter Waves, 2011, 30(2): 104-114. http://d.old.wanfangdata.com.cn/Periodical/hwyhmb201102002
    [10] MOUILLOTA F, SCHULTZ M G, YUE C, et al. Ten years of global burned area products from spaceborne remote sensing:a review:analysis of user needs and recommendations for future developments[J]. International Journal of Applied Earth Observation and Geoinformation, 2014, 26(1): 64-79. https://www.sciencedirect.com/science/article/pii/S0303243413000639
    [11] 焦琳琳, 常禹, 申丹, 等.利用增强回归树分析中国野火空间分布格局的影响因素[J].生态学杂志, 2015, 34(8): 2288-2296. http://d.old.wanfangdata.com.cn/Periodical/stxzz201508030

    JIAO L L, CHANG Y, SHEN D, et al. Using boosted regression trees to analyze the factors affecting the spatial distribution pattern of wildfire in China[J]. Chinese Journal of Ecology, 2015, 34(8): 2288-2296. http://d.old.wanfangdata.com.cn/Periodical/stxzz201508030
    [12] 黄宝华, 张华, 孙治军, 等.基于GIS与RS的山东森林火险因子及火险区划[J].生态学杂志, 2015, 34(5): 1464-1472. http://d.old.wanfangdata.com.cn/Periodical/stxzz201505041

    HUANG B H, ZHANG H, SUN Z J, et al. Forest fire danger factors and their division in Shandong based on GIS and RS[J]. Chinese Journal of Ecology, 2015, 34(5): 1464-1472. http://d.old.wanfangdata.com.cn/Periodical/stxzz201505041
    [13] FANG L, YANG J, ZU J, et al. Quantifying influences and relative importance of fire weather, topography, and vegetation on fire size and fire severity in a Chinese boreal forest landscape[J]. Forest Ecology and Management, 2015, 356(23): 2-12. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cb11e99159bd7de1d0a708b5f9bd2cc0
    [14] GUO F, INNES J L, WANG G, et al. Historic distribution and driving factors of human-caused fires in the Chinese boreal forest between 1972 and 2005[J]. Journal of Plant Ecology, 2015, 8(5): 480-490. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=b0a8323080ece3f271df8f741ec5e729
    [15] KUSHLA J D, RIPPLE W J. The role of terrain in a fire mosaic of a temperate coniferous forest[J]. Forest Ecology and Management, 1997, 95(2): 97-107. doi: 10.1016/S0378-1127(97)82929-5
    [16] 苏漳文, 宋禹辉, 郭福涛, 等.地形环境因素对塔河林业局人为森林火灾发生的影响[J].火灾科学, 2015, 24(1): 16-25. doi: 10.3969/j.issn.1004-5309.2015.01.03

    SU Z W, SONG Y H, GUO F T, et al. Influence of geographical and environmental factors on human-caused fires in Tahe area[J]. Fire Safety Science, 2015, 24(1): 16-25. doi: 10.3969/j.issn.1004-5309.2015.01.03
    [17] 陈正洪.鄂西山区森林火灾的分布特征及与地形气候的关系[J].地理研究, 1992, 11(3): 98-100. http://www.cnki.com.cn/Article/CJFDTotal-DLYJ199203021.htm

    CHEN Z H. Horizontal and vertical distribution of forest fire disasters in western Hubei and its corrleation with topographic climate[J]. Geographical Research, 1992, 11(3): 98-100. http://www.cnki.com.cn/Article/CJFDTotal-DLYJ199203021.htm
    [18] 张建龙.中国林业统计年鉴[M].北京:中国林业出版社, 2014.

    ZHANG J L. China forestry statistical yearbook[M]. Beijing: China Forestry Publishing House, 2014.
    [19] 何诚, 巩垠熙, 张思玉, 等.基于MODIS数据的森林火险时空分异规律研究[J].光谱学与光谱分析, 2013, 33(9): 2472-2477. doi: 10.3964/j.issn.1000-0593(2013)09-2472-06

    HE C, GONG Y X, ZHANG S Y, et al. Forest fire division by using MODIS data based on temporal-spatial variation law[J]. Spectroscopy and Spectral Analysis, 2013, 33(9): 2472-2477. doi: 10.3964/j.issn.1000-0593(2013)09-2472-06
    [20] 中国科学院地理研究所.中国1:1000000地貌图制图规范(试行)[M].北京:科学出版社, 1987.

    Institute of Grographic Sciences and Natural Resources Research. The mapping criterion of geomorphological map of China(1:1000000)[M]. Beijing:Science Press, 1987.
    [21] 刘颖, 邓伟, 宋雪茜, 等.基于地形起伏度的山区人口密度修正:以岷江上游为例[J].地理科学, 2015, 35(4): 444-470. http://www.cnki.com.cn/Article/CJFDTotal-DLKX201504011.htm

    LIU Y, DENG W, SONG X Q, et al. Population density correction method in mountain areas based on relief degree of land surface:a case study in the upper Minjiang River Basin[J]. Scientia Geographica Sinica, 2015, 35(4): 444-470. http://www.cnki.com.cn/Article/CJFDTotal-DLKX201504011.htm
    [22] 郭芳芳, 杨农, 孟晖, 等.地形起伏度和坡度分析在区域滑坡灾害评价中的应用[J].中国地质, 2008, 35(1): 131-143. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi200801014

    GUO F F, YANG N, MENG H, et al. Application of the relief amplitude and slope analysis to regional landslide hazard assessments[J]. Geology in China, 2008, 35(1): 131-143. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi200801014
    [23] 张军, 李晓东, 陈春燕, 等.新疆地势起伏度的分析研究[J].兰州大学学报(自然科学版), 2008, 44(增刊1): 10-19. http://www.cnki.com.cn/Article/CJFDTotal-LDZK2008S1004.htm

    ZHANG J, LI X D, CHEN C Y, et al.Analysis of the relief amplitude in Xinjiang[J]. Journal of Lanzhou University(Natural Sciences), 2008, 44(Suppl.1): 10-19. http://www.cnki.com.cn/Article/CJFDTotal-LDZK2008S1004.htm
    [24] 王玲, 吕新.基于DEM的新疆地势起伏度分析[J].测绘科学, 2009, 34(1): 113-116. doi: 10.3771/j.issn.1009-2307.2009.01.038

    WANG L, LV X. Analysis of the relief amplitude in Xinjiang based on digital elevation model[J]. Science of Surveying and Mapping, 2009, 34(1): 113-116. doi: 10.3771/j.issn.1009-2307.2009.01.038
    [25] 哈凯, 丁庆龙, 门明新, 等.山地丘陵区土地利用分布及其与地形因子关系:以河北省怀来县为例[J].地理研究, 2015, 34(5): 909-921. http://d.old.wanfangdata.com.cn/Periodical/dlyj201505010

    HA K, DING Q L, MEN M X, et al. Spatial distribution of land use and its relationship with terrain factors in hilly area[J]. Geographic Research, 2015, 34(5): 909-921. http://d.old.wanfangdata.com.cn/Periodical/dlyj201505010
    [26] 李兴华.内蒙古东北部森林草原火灾规律及预警研究[D].北京: 中国农业科学院, 2007. http://cdmd.cnki.com.cn/Article/CDMD-82101-2007156160.htm

    LI X H. Study of forest and grasslands conflagration law and early warning in the north-east of Inner Mongolia[D].Beijing: Chinese Academy of Agriculture Sciences, 2007. http://cdmd.cnki.com.cn/Article/CDMD-82101-2007156160.htm
    [27] 朱霁平, 刘小平, 林其钊, 等.变坡度情况下森林地表上坡火行为若干特征的实验研究[J].火灾科学, 1999, 8(2): 63-71. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199900318083

    ZHU J P, LIU X P, LIN Q Z, et al. Experimental study on upslope forest surface fire upon changing slope[J]. Fire Safety Science, 1999, 8(2): 63-71. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199900318083
    [28] 曲炤鹏, 郑淑霞, 白永飞.蒙古高原草原火行为的时空格局与影响因子[J].应用生态学报, 2010, 21(4): 807-813. http://d.old.wanfangdata.com.cn/Periodical/yystxb201004001

    QU S P, ZHENG S X, BAI Y F. Spatiotemporal patterns and driving factors of grassland fire on Mongolian Plateau[J]. Chinese Journal of Applied Ecology, 2010, 21(4): 807-813. http://d.old.wanfangdata.com.cn/Periodical/yystxb201004001
